The easiest way to scan. Just plug-and-play


There is no need to use a controller with the Solano 3D laser scanner. Just connect it to any type of measuring arm and work with different software applications. The good quality/price ratio of the Solano makes it a must-have of our scanner range. Discover also Solano Lite as the most affordable scanner in the Kreon product range.


40 000 pts/s


30 μm

Laser line width

100 mm


Touch probe integration
Stand-alone or plug-in software
Auto Quality Check
Portable and flexible solution


Plug-and-play (no controller)
Easy to use
Quick set-up
Fast learning

To get more information please contact us

Contact us

Solano Lite

Based on the Solano technology, the Solano Lite is efficient, more economic and still compatible with any type of measuring arm.

Technical specifications:

Measurement speed: 24 000 points/second
Accuracy: 40 μm
Laser line width: 100 mm
Stand-off distance: 50 mm

Machine specifications

Machine interface Articulated arms
Probe compatibility under the scanner Hard probe
PC communication Ethernet – External wire communication for the Solano Lite

Scanner specifications

Line resolution 140 µm
Stand-off distance 50 mm
Field of view 100 mm
Temperature compensation Yes
Laser class Red Class 2M
