New measuring arm
The best of ACE arm, and even more
The ACE+ arm is our new 3D measuring solution for the most challenging parts. With unprecedented levels of precision, it satisfies all digital needs, for both scanning and probing.
Targeted adjustments for increased performances
ISO compliance
Fully compliant with the ISO 10360-12 standard, the ACE+ arm ensures greater precision, more consistent measurements over its volume, and higher repeatability.
Advanced calibration
A state-of-the-art calibration process makes the ACE+ particularly accurate.
Optimized encoders
Precision is further enhanced by new ways of optimising the accuracy of the encoders used for the ACE+ articulations.
Ace+ 7 axis
| Arm model | E Uni | P Size | P Form | L Dia | SPAT |
| Ace+7-25 | 0.033 mm | 0.012 mm | 0.022 mm | 0.047 mm | 0.025 mm |
| Ace+7-30 | 0.057 mm | 0.017 mm | 0.030 mm | 0.074 mm | 0.039 mm |
| Ace+7-35 | 0.067 mm | 0.021 mm | 0.037 mm | 0.089 mm | 0.045 mm |
| Ace+7-40 | 0.084 mm | 0.026 mm | 0.042 mm | 0.105 mm | 0.054 mm |
| Ace+7-45 | 0.105 mm | 0.040 mm | 0.051 mm | 0.114 mm | 0.067 mm |
