Desktop 3D Scanner

RangeVision Smart

RangeVision Smart is a desktop 3D scanner of high resolution. Ease of use, affordable price and wide range of applications make Smart stand out from its competitors.

Due to the use of structured light technology, Smart 3D scanner provides highly accurate and detailed scans. Its accuracy is up to 0,1% from the original object, resolution – up to 0,12 mm. Technical equipment of RangeVision Smart 3D scanner provides ease of use and a wide range of applications. it is ideal for digitization of objects from 4 cm to 1 m.

The absence of manual setting and autofocus provides fast and simple calibration of the scanner. Two cameras make it possible to use markers and align obtained scans in automatic mode.

rangevision smart


Ease of use

RangeVision Smart is fully assembled and ready to use – just remove the equipment from the case, connect it to the computer and get to work. Smart 3D scanner is equipped with two cameras and autofocus, which simplifies its calibration.

Mobility and compactness

Low user engagement in the process of scanning is provided by the fact, that RangeVision Smart is able to work offline without connecting to the network for 1 hour. Smart and its accessories is very lightweight, at less than 2 kg, allowing for easy transportation to the sites and offices of the customers in a secure case. Smart is widely used in art and designing sculptures, reverse engineering and industrial design.

Affordable price

Being a budget solution on the market of 3D scanning, Smart established itself as a unique sample of value for money, that makes the equipment stand out from its competitors.

1.3 MPix, 1/4"
Scan speed
4-12 sec
WVGA (854х480)
Cameras manufacturer
IDS (Germany)
Light source
Scanning principle
Structured light
Scanning modes
Free scanning, with markers, on turntable
Scanning with color textures
Output formats
HDMI, 2xUSB 2.0
220V, 40W
Output formats
7 min
Dimensions of scanning unit (WxHxL)
320х80х150 mm
1.25 kg
Scanning Zones [1] [2] [3]
Scanning area (mm) 500x375x375 300x225x225 150x112x112
3D resolution (mm) 0.4 0.24 0.12
Automatic turntable TL

Automated 360 degree scanning with any of the turntable system developed by RangeVision will make the scanning process faster and easier. Reinforced TL is intended for different-sized objects weighing up to 50 kg.

Additional license key

In the case of a large amount of work, the workflow can be splitted between two operators: one scans and the other works with a scanned data. This approach allows you to significantly speed up the process.

Automatic turntable TS
Compact and light weight model TS is perfect solution for scanning small and medium-sized objects weighing up to 5 kg.
Operation system
Windows 7/8/10 64bit
Intel Core i3/i5 1.8 GHz or better
Graphics hardware
Video card with dual monitor support
At least 4 GB
3 USB ports

The standard package includes:

  • The scanning module
  • Two cameras with non-replaceable lenses with autofocus
  • Set of calibration plates
  • Travel case
  • Tripod
  • Digital license key
  • Set of self-adhesive markers

*Automatic turntable is optional.

rangevision spectrum equipment
rangevision software


The RangeVision software, specially designed for fast processing of scan results, comes with a 3D scanner. At the end of the scan, the RangeVision software will help you optimize the resulting 3D model with automated functions: stitching fragments, filling voids, aligning the 3D model. As a result, you get a high-precision 3D copy of the object.

STL output data format is suitable for working with 3D models in all popular CAD / CAM programs: Solidworks, Autocad and others, as well as virtual modeling environments: 3Ds Max, Maya, Rhinoceros. Free software updates are always included in the cost of the 3D scanner.

Learn More


Reverse engineering and rapid prototyping


Restoration and preservation of cultural heritage

Furniture and decor
